型號 |
PUA2 |
PUA5 |
PUA8 |
應用 |
用于測量反光金屬和高溫物體 |
用于測量玻璃表面溫度 |
通用型,用于測量非反光材質 |
光譜范圍 |
2.2 μm |
5 μm |
8~14 μm |
溫度范圍 |
45~2000°C (依選型) |
200~1650℃ |
-40~1000℃ |
響應時間,t90 |
200 ms @90% |
輸出信號 |
2-wire, 4-20 mA, linear with measured temperature |
通訊介面 |
USB 2.0 (removable USB cable and software included) using the Modbus protocol |
精確值 |
± 2°C or 1% of reading,
whichever is greater |
± 1°C or 1% of reading,
whichever is greater |
重復性 |
± 0.5°C or 0.5% of reading, whichever is greater |
放射率 |
0.1 to 1.0 (Adjustable via software) |
焦距比(依選型) |
15:1?
|
25:1 |
30:1 |
25:1 |
75:1?
|
Close Focus ? 5 mm @ 100 mm |
Close Focus ?7.5mm @ 500mm |
最大跨度
(4-20mA輸出) |
Full temperature range |
最小跨度
(4-20mA輸出) |
100°C |
環境溫度 |
0°C to 70°C (cooled models are available for higher temperatures) |
相對濕度 |
95% max. non-condensing |
供應電源 |
24 V DC (28 V DC max) |
Sensor電源 |
6 V DC (min.) |
最大回路阻抗 |
900 Ω @ 24 V DC |
結構 |
Stainless Steel |
外型尺寸 |
? 27.6 x length 61 mm including cable glands |
螺紋安裝 |
M20 x 1 mm pitch, length 15 mm |
4-20mA輸出 線長 |
1 m (標準), up to 30 m (選用) |
USB 線長 |
1.8 m |
防護等級 |
IP65 |
重量 |
175g |
應用案例 |
【PUA2】 |
.鋼鐵擠壓 / 鍛造 / 鑄造
應用于一般鋼帶溫度測量;熱爐前的鋼溫度測量和熱軋機上卷取機的溫度。
.高溫爐 / 烤箱
測量爐內的熱物體,如:鋼廠熱處理爐。
.軸承 / 齒輪
短波長測量,對反射引起的誤差不太敏感,可測量軸承/齒輪的表面溫度。
.風力
監測風力發電機的制動盤表面溫度,以幫助警告過熱和優化冷卻循環。
.食品
可穿透玻璃,測量玻璃容器內熱食品的溫度,溫度范圍45°C~300°C。
|
【PUA8】 |
.風力
可用于測量渦輪機的非反射部件溫度,如齒輪箱和軸承座。
.印刷
即使在非常低的溫度下,也能精確測量紙張溫度。 |
